CGZH Laboratory Flotation Machine with Low Energy Consumption Large Processing Capacity and Small Footprint
  • name

CGZH Laboratory Flotation Machine with Low Energy Consumption Large Processing Capacity and Small Footprint

MOQ: 1
Price: Negotiate
Standard Packaging: Standard export packing is provided, and customized packing is available upon request.
Delivery Period: 1-3 working days
Payment Method: T/T,L/C
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Y&X
Certification
Iso 9001
Model Number
flotation column
Name:
Flotation Column
Type:
CGZH
Feature:
Low Energy Consumption
Advantage:
Large Processing Capacity
Tailings Ash:
45%-70%
Purpose:
Extract Clean Coal From Coal Washing Water
Structure::
The Equipment Occupies A Small Area,
Energy:
Low Consumption
Highlight:

120t/h Laboratory Flotation Machine

,

150t/h Laboratory Flotation Machine

,

45kw column flotation cell

Product Description
CGZH Laboratory Flotation Machine Column Flotation Cell
Laboratory CGZH Flotation Column

This product is an energy-saving, high-efficiency, and environmentally friendly rapid flotation machine developed through continuous practice. It features small footprint, low energy consumption, simple operation, minimal maintenance, large processing capacity, and high clean coal recovery rate.

Main Features
  • Adjustable flotation clean coal ash content: 6% to 12%
  • Tail coal ash content: 45% to 70%
  • Extracts 60% to 90% qualified clean coal from one ton of coal slime
  • Flotation clean coal accounts for approximately 10% of washed clean coal output
Purpose

Extracts clean coal from coal washing water. Compatible with all jigging coal washing machines, side drum coal washing machines, and underscreen air chamber coal washing machines under 15 square meters.

Structure Advantages
  • Small footprint: 6-7 * 6-7 (㎡) per unit
  • Easy operation: One person per unit per shift
  • Minimal maintenance: Only two pumps require maintenance
  • Low power consumption: 50-100 kilowatts
  • No concentration equipment needed: Saves approximately ¥250,000 investment
Technical Parameters
Parameter Item Unit CGZH2500 CGZH2900 CGZH3250
Throughput t/h ≤120 ≤150 ≤250
Feed Concentration g/L ≤120 ≤120 ≤120
Flotation Power kw 15+30 22+37 30+55
Filter Press Power kw 37+10 37+15 37+20
Company Profile

Y&X Beijing Technology Co., Ltd., established in 2014 and located in Beijing, China, is a professional enterprise integrating scientific research, design, product development, and manufacturing. The company specializes in mineral processing reagents and equipment for metallurgy, geology, petroleum, coal, chemicals, building materials, environmental protection, and mining industries.

Products are exported to Russia, Mongolia, Chile, Australia, Zimbabwe, Thailand, Laos, Indonesia, Tanzania, Nigeria, and other countries. The company holds ISO9001 quality management system certification.

CGZH Laboratory Flotation Machine Column Flotation Cell
Frequently Asked Questions
Q1: What is the CGZH flotation column used for?
It is an energy-saving, high-efficiency, and environmentally friendly rapid flotation machine mainly used to extract clean coal from coal washing water. Compatible with all jigging coal washing machines, side drum coal washing machines, and underscreen air chamber coal washing machines under 15 square meters.
Q2: What are the main advantages of this equipment?
Small footprint of only 6-7*6-7 (㎡) per unit, low energy consumption, simple operation with only one person per unit per shift, minimal maintenance with only two pumps, large processing capacity, and high clean coal recovery rate.
Q3: What are the key performance indicators?
Flotation clean coal ash content adjustable between 6% and 12%, tail coal ash content reaching 45%-70%, and 60%-90% qualified clean coal extraction from one ton of coal slime.
Q4: What are the main technical parameters?
Models CGZH2500, CGZH2900, and CGZH3250 offer throughput of ≤120 t/h, ≤150 t/h, and ≤250 t/h respectively, with feed concentration ≤120 g/L, flotation power of 15+30kw, 22+37kw and 30+55kw, and filter press power of 37+10kw, 37+15kw and 37+20kw.
Q5: What is your MOQ and delivery time?
MOQ is 1 unit for trial orders. Small orders delivered within 1-3 working days, mass production takes 3-10 working days. Final lead time confirmed on individual invoices.
Q6: What after-sales service and certification do you provide?
Complete after-sales support including installation guidance, operation training, and spare parts supply. Company holds ISO9001 quality management system certification, with every machine strictly inspected before shipment.
