Product Details:
|
| Name: | Rod Mill | Type: | XMB70 |
|---|---|---|---|
| Model: | Three Roller And Four-drum | Feature: | Small, Lightweight And Versatile |
| Usage: | Dry And Wet Dual Use | Purpose: | Coal And Colleges |
| Grinding Amount: | <50 | Feed Size: | -0.5 |
| High Light: | 0.25l laboratory ball mill machine,0.25l ball mill machine for laboratory,three roller laboratory ball mill machine |
||
Low Noise 0.25L Laboratory Ball Mill Machine Three Roller Four Drum Rod XMB70
Introduction Introduction:
XMB70 type three-roll four-cylinder rod mill is a small, lightweight and multi-purpose new type of grinding equipment for laboratory use. It can grind ore in a single cylinder or multiple cylinders at the same time. The steel rod is used as a ball mill, and the frequency conversion technology of the machine ensures a wide range of speed regulation and a stable speed change. Available for metallurgy, geology, chemical industry, building materials, coal and colleges and universities, it is used for grinding fine ore in scientific research institutes, mine concentrators, etc. when conducting research on ore selectivity.
Technical Parameters:
| Name | Specification | Unit | ||||
|
Mill barrel |
Volume | 0.25 | 0.5 | 1 | 2 | L |
|
Diameter×Length |
Φ65×76 | Φ80×100 | Φ102×125 | Φ132×150 | mm | |
| Grinding amount | <50 | 50~100 | 100~200 | 250~400 | g | |
| Feed Size | -0.5 | -0.5 | -1 | -2 | mm | |
| Discharging Size | -0.074 | -0.074 | -0.074 | -0.074 | mm | |
| Spindle roller Speed | 233,258,281,312(Frequency control0-300) | R/min | ||||
| Power | 0.37 | Kw | ||||
| Outline Size | 760×510×520 | mm | ||||
| Weight | 115 | Kg | ||||
Company profile
Y&X Beijing Technology Co., Ltd. was established in 2014 and is located in Beijing, the capital of China. Our company has become a professional enterprise integrating scientific research, design, new product development, production and manufacturing with strong technical force. As a family group, the mission from the beginning was to expand overseas markets and provide one-stop professional for overseas mining companies.
The company specializes in the research and supply of mineral processing reagents and equipments, including mineral processing equipment and laboratory mineral processing equipment; products are widely used in metallurgy, geology, petroleum, coal, chemicals, building materials, environmental protection, non-ferrous and non-metallic mines, Research departments in industries such as dressing plants, mineral processing laboratories in colleges and universities.
Laboratory equipment for mineral processing: mainly include crushing, grinding, screening, grading, magnetic separation, flotation, assay, sample preparation, leaching, analysis-electrolysis, shaking table, chute and other laboratory equipment and gravity separation equipment.
Our products sell well in Russia, Mongolia, Chile, Australia, Zimbabwe, Thailand, Laos, Indonesia,Tanzania, Nigeria and other countries and regions.
The enterprise has passed the IS09001 quality management system certification, and the product quality conforms to the relevant technical standards promulgated by the state and the enterprise.
