Product Details:
|
| Name: | Planetary Four-cylinder Mill | Model: | Planetary Four-cylinder |
|---|---|---|---|
| Type: | XPML- Φ100×4 | Function: | Efficient, Multi-grain Adjustable |
| Advantage: | Wide Speed Range | Material: | Agate Material, Corundum |
| Avoid: | Iron Supplies | Attributes: | Grinding Equipment |
| High Light: | planetary four cylinder laboratory grinding mill,xpml 100mm × 4 laboratory grinding mill,four cylinder ball mill for laboratory |
||
Four Cylinder Laboratory Grinding Mill XPML 100MM × 4 Ball Mill For Laboratory
Introduction Introduction:
XPML-Φ100×4 planetary four-cylinder grinder is a kind of high-efficiency, multi-grain adjustable grinding equipment which is improved and designed on the basis of absorbing foreign advanced experience. Because the grinding body is in the centrifugal force field of 12-13g for grinding motion, the grinding efficiency is high, and the discharge particle size is fine and uniform. The equipment adopts AC frequency conversion technology, which can realize the stepless speed regulation of the grinding disc, and has a wide speed regulation range, stable speed change, and a timing device to ensure the repeatability of grinding conditions. In addition, different specifications of quenched stainless steel grinding cylinder or agate material, corundum and other grinding cylinders can be selected to be suitable for grinding various materials, especially
It is suitable for grinding and superfine grinding of iron-avoiding materials.
Technical Parameters:
| project | Unit | XPML- Φ100×4 |
| Number of grinding cylinders | piece | 4 |
| Turntable speed | r/min | 100-400 Variable frequency stepless speed regulation |
| Grinding drum speed | r/min | 224-896 Variable frequency stepless speed regulation |
| Grinding drum loading amount per drum | g | 200 ,150 ,100 ,50 (Symmetrical options available) |
| Charge particle size | mm | ≤5； (Max≤10) |
| Product particle size | mm | ≤0.074 |
| Inverter frequency range | Hz | 10-35 |
| Motor model | kw | YD90-4L 1.5 |
| Motor speed | r/min | 1400 |
| Dimensions (L×W×H) | mm | 600×666×1067 |
| reference weight | Kg | 240 |
