Model GC-6890B High-performance Gas Chromatograph for Chemical Test

I'm Online Chat Now

Model GC-6890B High-performance Gas Chromatograph for Chemical Test

Model GC-6890B High-performance Gas Chromatograph for Chemical Test
Model GC-6890B High-performance Gas Chromatograph for Chemical Test

Large Image :  Model GC-6890B High-performance Gas Chromatograph for Chemical Test

Product Details:
Place of Origin: China
Brand Name: Y&X
Certification: ISO9001
Model Number: Model GC-6890B
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: Cartons
Delivery Time: 1-3 working day
Payment Terms: T/T, L/C

Model GC-6890B High-performance Gas Chromatograph for Chemical Test

Name: Model GC-6890B High-performance Gas Chromatograph For Chemical Test Model: Model GC-6890B
Classification: Chromatograph Application: Chromatograph
Advantage: Dual CPU Design Machine: High-tech Precision Products

Model GC-6890B High-performance Gas Chromatograph for Chemical Test



Product description

A new generation of domestically produced high-performance gas chromatograph, with powerful functions, excellent performance, reliable operation, easy to learn and use, high cost-effectiveness, and beautiful appearance.


Basic configuration of the host:
Gas interruption protection, Japanese original integrated circuit, dual CPU, Chinese keyboard operation, large screen LCD display, power failure protection, over temperature protection, Japanese original stepper motor, intelligent rear door opening, fifth order program heating, self diagnosis and display of fault causes, codes and processing methods, six temperature control, quartz nozzle (FID), pure silver polarizing electrode (FID), imported rhenium tungsten wire (TCD), adjustable background light, adjustable alarm volume, heating power consumption percentage display, stopwatch function, etc.


Main technical indicators:

Detector Sensitivity or sensitivity Drift Noise Linear range Introduction to Features
Hydrogen flame (FID)



0.15mV/h 20uV ≥10-7 Pure silver polarized quartz nozzle
Thermal conductivity (TCD) S≥ 0.15mV/h 20uV ≥10-5 Imported rhenium tungsten wire constant current source
Electron Capture (ECD) Mt≤1×10-13g/ml 0.15mV/h 20uV ≥10-4 High temperature resistant Ni63 radiation source
Flame Photometry (FPD) Mt≤1×10-12g/s(P)
0.15mV/h 20uV ≥10-3 Single flame design
Nitrogen and phosphorus (NPD) Mt≤1×10-12g/s(N)
0.15mV/h 20uV ≥10-3 Imported rubidium beads




Instrument Advantage

1. A brand new Japanese original digital circuit with dual CPU design, powerful functions, excellent reliability and anti-interference ability, greatly improving temperature control accuracy and overall stability.
2. Chinese keyboard operation, large LCD display screen, rich and intuitive display content, and the screen background brightness can be adjusted according to ambient light.
3. Automatic alarm function: The alarm volume can be adjusted according to environmental noise.
4. Gas interruption protection function: When the carrier gas pressure is below 0.1MPa, the instrument will automatically alarm, indicating that the heating area power cannot be heated or automatically cut off, and the thermal conductivity detector will automatically cut off the bridge current, effectively protecting the instrument and chromatographic column.
5. It has a fifth order programmed heating function, which greatly meets the analysis of complex samples with a wide boiling range and multiple components.
6. It has six independent temperature control systems that can simultaneously control six heating zones, meeting the needs of multiple temperature control. It can conveniently expand multiple detectors, conversion furnaces, etc.
7. Intelligent rear door opening, super large ventilation opening, using imported Japanese original stepper motor, stepless adjustable inlet and outlet air volume, fast temperature rise and fall, greatly reducing the stable time of program temperature analysis cycle, and greatly improving work efficiency. When the working temperature of the column box is close to room temperature, the rear door will automatically adjust the angle of the door opening, control the inlet and outlet air volume, and achieve true near room temperature operation.
8. Parameter storage protection function: After the instrument is turned off, the main power switch of the instrument only needs to be turned on for the next time it is turned on. The instrument will automatically operate according to the state before the last shutdown, realizing the true "one click power on" function. If the power is restored after a power outage, the instrument will automatically return to the operating state before the power outage.
9. Equipped with stopwatch and flow calculation functions: The precise and practical stopwatch function can not only measure the retention time of a specific sample peak, but also automatically calculate and display the real-time flow rate of gas.
10. The pneumatic system adopts a design of precision stabilizing valve and precision stabilizing flow valve, ensuring high stability of the airflow, thereby maximizing the high reproducibility and accuracy of the analysis results.
11. Unique injection port design solves injection discrimination and enables multiple injection methods: filling column head injection, filling column vaporization injection, capillary split/non split injection, six way valve gas injection, automatic headspace injection, and automatic sampler injection.
12. Three injection ports (two filling column injection ports and one capillary column injection port) and four types of detectors can be installed simultaneously, and the six way valve gas injector, conversion furnace, and dual FID amplifier can be expanded, truly achieving one machine with multiple uses.
13. The first domestically developed thermal conductivity detector with both packed and capillary columns.
14. More humanized designs.



Company profile

Y&X Beijing Technology Co., Ltd. was established in 2014 and is located in Beijing, the capital of China. Our company has become a professional enterprise integrating scientific research, design, new product development, production and manufacturing with strong technical force. As a family group, the mission from the beginning was to expand overseas markets and provide one-stop professional for overseas mining companies.

The company specializes in the research and supply of mineral processing reagents and equipments, including mineral processing equipment and laboratory mineral processing equipment; products are widely used in metallurgy, geology, petroleum, coal, chemicals, building materials, environmental protection, non-ferrous and non-metallic mines, Research departments in industries such as dressing plants, mineral processing laboratories in colleges and universities.

Laboratory equipment for mineral processing: mainly include crushing, grinding, screening, grading, magnetic separation, flotation, assay, sample preparation, leaching, analysis-electrolysis, shaking table, chute and other laboratory equipment and gravity separation equipment.

Our products sell well in Russia, Mongolia, Chile, Australia, Zimbabwe, Thailand, Laos, Indonesia,Tanzania, Nigeria and other countries and regions.

The enterprise has passed the IS09001 quality management system certification, and the product quality conforms to the relevant technical standards promulgated by the state and the enterprise.
