5L 73MM FJⅡ Multi Energy Mechanical Laboratory Flotation Cell

I'm Online Chat Now

5L 73MM FJⅡ Multi Energy Mechanical Laboratory Flotation Cell

5L 73MM FJⅡ Multi Energy Mechanical Laboratory Flotation Cell
5L 73MM FJⅡ Multi Energy Mechanical Laboratory Flotation Cell

Large Image :  5L 73MM FJⅡ Multi Energy Mechanical Laboratory Flotation Cell

Product Details:
Place of Origin: China
Brand Name: Y&X
Certification: ISO9001
Model Number: multi-energy flotation machine
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: Cartons
Delivery Time: 1-3 working day
Payment Terms: T/T, L/C

5L 73MM FJⅡ Multi Energy Mechanical Laboratory Flotation Cell

Name: Multi-energy Flotation Machine Type: FJⅡ Type
Model: Multi-energy Purpose: Coal, Chemical
Advantage: Stable And Reliable Operation Test: Continuous Flotation Experiments
Slot Selection Volume: 5L Slot/Group: 12 Slot /6 Group
High Light:

5L laboratory flotation cell


73MM multi energy laboratory flotation cell


mechanical flotation cell ISO9001

FJⅡ type multi-energy flotation machine


Main uses and features:

FJ multi-energy flotation machine is suitable for continuous flotation experiments of laboratory stirring, scrubbing, separation and selection of a small amount of mineral samples in metallurgy, geology, coal, chemical, petroleum and other industries. It can also be used for the research of new models and the experimental work of model selection. The machine adopts frequency conversion technology, impeller stepless speed regulation, digital display, adopts external inflation device, central inflation, adjustable inflation volume, accurate adjustment, accurate and stable, stable and reliable operation. The temperature control device can be customized according to user needs.



Main technical parameters of FJⅡ flotation machine
No. Project Unit Parameter
1 Slot selection volume L 3 5 7
2 Slot/Group 12 Slot
/6 Group
2 Slot 1 Group (2 groups in total) 2 Slot 1 Group (2 groups in total) 2 Slot 1 Group (2 groups in total)
3 Diameter of impeller mm Φ73 Φ95
4 Stator diameter mm Φ95 Φ120
5 Stand-alone standard number of working slots 2 Slot
/1 Group
6 Slot 3 Group
6 Impellr speed r/min 0-2400
7 Scraping times r/min 30,60
8 Stiring motor Power model 250W (A02-6322) 220V
9 Scraping motor Power model 16W (70TDY4) 220V
10 Dimensions mm 1400×700×2000


Company profile

Y&X Beijing Technology Co., Ltd. was established in 2014 and is located in Beijing, the capital of China. Our company has become a professional enterprise integrating scientific research, design, new product development, production and manufacturing with strong technical force. As a family group, the mission from the beginning was to expand overseas markets and provide one-stop professional for overseas mining companies.

The company specializes in the research and supply of mineral processing reagents and equipments, including mineral processing equipment and laboratory mineral processing equipment; products are widely used in metallurgy, geology, petroleum, coal, chemicals, building materials, environmental protection, non-ferrous and non-metallic mines, Research departments in industries such as dressing plants, mineral processing laboratories in colleges and universities.

Laboratory equipment for mineral processing: mainly include crushing, grinding, screening, grading, magnetic separation, flotation, assay, sample preparation, leaching, analysis-electrolysis, shaking table, chute and other laboratory equipment and gravity separation equipment.

Our products sell well in Russia, Mongolia, Chile, Australia, Zimbabwe, Thailand, Laos, Indonesia,Tanzania, Nigeria and other countries and regions.

The enterprise has passed the IS09001 quality management system certification, and the product quality conforms to the relevant technical standards promulgated by the state and the enterprise.

5L 73MM FJⅡ Multi Energy Mechanical Laboratory Flotation Cell 0


FAQ to save your precious time!


Q1: What's the standard length of your profiles and tube?

A: The standard length of profiles and tube are 5800mm to suit for small container, and we also can cut to specific length, however a surcharge of machining and material scrap cost will be charged accordingly based on each individual invoice.


Q2: What's your MOQ?

A: we have no MOQ for our new customers, however a surcharge of USD80 will apply for all orders less that USD 1000 for custom handing cost purpose.


Q3: what is your payment terms?

A: The payment terms we accept is T/T or irrevocable L/C at sight, T/T preferred.


Q4: What's the lead time for small order and mass production?

A: 1-3 working days for small order, and 3-10 working days for mass production of material, and the final lead time will be subject to each individual invoice.


Q5: What certification do you have?

A: We have ISO 9001:2008 certificate.
