|Laboratory ZM-T Vibration Mill
|Simple And Convenient Operation
|Light Weight And Small Size
30l laboratory disc mill,
electronics industry laboratory disc mill
30L ZMT Vibration Ball Mill Laboratory Disc Mill For Electronics Industry
Main uses and features:
Vibration mill is a ball milling chamber fixed with the lower vibration mechanism. The vibration motor drives two adjustable eccentric blocks to rotate to make the cylinder vibrate, forcing the grinding medium and the material in the cylinder to vibrate at high frequency, so that the material is affected by the grinding medium. Strong impact, friction and shearing action crush the material. The fine particles re-enter the ball milling chamber through the peristaltic pump through the screen bar at the lower part of the grinding chamber, and the coarse particles remain in the grinding chamber to continue ball milling. The machine is very mature in both structure and process configuration; it is widely used in electronics, ceramics, chemical industry, powder metal, tungsten, calcium carbide, rubber compounds, magnetic materials and high-frequency ceramic materials and pharmaceuticals in the radio industry. Special Options: Cylinder Lining: Optional stainless steel, ceramic (alumina), zirconia, ceramic tile, nylon, teflon, food grade rubber or polyurethane liners.
|The main technical parameters
|ZM-T Vibration Mill
|Grinding jar volume
|1~50L can be made according to needs
|Grinding jar lining
|Stainless steel, ceramics, zirconia, nylon, PTFE, polyurethane, etc. can be selected according to needs.
|Maximum filling per can
|The material and grinding medium do not exceed two-thirds of the volume
|Feed particle size
|Crunchy materials less than 20mm, others less than 10mm
|Discharge particle size
|down to 0.5 microns
|Vibration frequency and amplitude
|Frequency 23/46HZ, amplitude 5-7mm
1. Simple and convenient operation, reliable work, easy to clean, and strong adaptability to working conditions.
2. No environmental pollution, dry and wet ball milling can be performed.
3. Light weight, small size, high efficiency, can be made into continuous production type.
