3.5t 150mm Laboratory PEX Impact Mill Rock Mini Jaw Crusher

I'm Online Chat Now

3.5t 150mm Laboratory PEX Impact Mill Rock Mini Jaw Crusher

3.5t 150mm Laboratory PEX Impact Mill Rock Mini Jaw Crusher
3.5t 150mm Laboratory PEX Impact Mill Rock Mini Jaw Crusher

Large Image :  3.5t 150mm Laboratory PEX Impact Mill Rock Mini Jaw Crusher

Product Details:
Place of Origin: China
Brand Name: Y&X
Certification: ISO9001
Model Number: PEX jaw crusher
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: Cartons
Delivery Time: 1-3 working day
Payment Terms: T/T, L/C

3.5t 150mm Laboratory PEX Impact Mill Rock Mini Jaw Crusher

Name: PEX Jaw Crusher Attributes: Jaw Crusher
Type: PEX Purpose: Nuclear Industry
Industry: Departmental Laboratory Feature: Broken Ratio
Advantge: Easy To Adjust Weight: 3.5t
High Light:

3.5t impact mill rock crusher


150mm impact mill rock crusher


1180mm mini jaw crusher machine

Laboratory PEX jaw crusher


Main uses and features:

This machine is a deep cavity type crushing and sample preparation equipment for compound pendulum motion. It can be used for crushing materials with a compressive strength not exceeding 250Mpa in laboratories of geology, metallurgy, coal, building materials, chemical industry, nuclear industry and other departments. use. The crushing ratio of the machine is large, the particle size of the product is uniform, and the adjustment is convenient. It is a kind of crushing and sample preparation equipment with one-stage crushing instead of multi-stage crushing, convenient material receiving, less working dust, high reliability and excellent performance.



The main technical parameters
parameter item Unit PEX-150×750 PEX-400×600 PEX-350×750
Inlet size mm 150×750 400×600 350×750
Maximum feed size mm 120 350 300
Discharge port adjustment range mm 10-40 40-100 15-50
maximum productivity m³/h 8~16 8~20 12~25
electric motor Y180L-6,15KW Y225M-8,30KW Y250M-8,30KW
Dimensions (L×W×H) mm 1180×1525×1060 1740×1390×1670 1650×1860×1600
Body net weight T 3.5 5.8 6.5


Company profile

Y&X Beijing Technology Co., Ltd. was established in 2014 and is located in Beijing, the capital of China. Our company has become a professional enterprise integrating scientific research, design, new product development, production and manufacturing with strong technical force. As a family group, the mission from the beginning was to expand overseas markets and provide one-stop professional for overseas mining companies.

The company specializes in the research and supply of mineral processing reagents and equipments, including mineral processing equipment and laboratory mineral processing equipment; products are widely used in metallurgy, geology, petroleum, coal, chemicals, building materials, environmental protection, non-ferrous and non-metallic mines, Research departments in industries such as dressing plants, mineral processing laboratories in colleges and universities.

Laboratory equipment for mineral processing: mainly include crushing, grinding, screening, grading, magnetic separation, flotation, assay, sample preparation, leaching, analysis-electrolysis, shaking table, chute and other laboratory equipment and gravity separation equipment.

Our products sell well in Russia, Mongolia, Chile, Australia, Zimbabwe, Thailand, Laos, Indonesia,Tanzania, Nigeria and other countries and regions.

The enterprise has passed the IS09001 quality management system certification, and the product quality conforms to the relevant technical standards promulgated by the state and the enterprise.
