Product Details:
|
| Name: | Small Scale Mineral Milling Machine Laboratory Vibrating Disc Mill | Attributes: | Milling Machine Laboratory |
|---|---|---|---|
| Model: | Vibrating Disc | Purpose: | Mine Laboratory |
| Output (kg/h): | 0.1 - 2 Kg/h | Feeding Size (mm): | 0 - 20 Mm |
| Output Size (mesh): | 100 - 200 Mesh | Application: | Small Scale Disc Mill |
| High Light: | small scale mineral milling machine,laboratory vibrating disc mineral milling machine,small scale laboratory vibrating disc mill |
||
Small Scale Mineral Milling Machine Laboratory Vibrating Disc Mill
Main uses and characteristics:
suitable for material crushing, sample preparation and testing in scientific research institutes and colleges and universities in industries such as geology, mining, metallurgy, coal, electric power, chemical industry, building materials, etc. Dust, easy to operate. This product is produced by the only enterprise designated by the original Ministry of Mines and Mines, and implements industry standards. GJ type sealed series laboratory sample preparation pulverizer adopts the "anti-loosening device for pressing the material bowl", which is light and reliable. Fully sealed, no dust spillage, no need for exhaust and dust removal.
Parameter
| The main technical parameters | ||||||
| parameter item Specification model" |
Number of samples (pieces) | Loading particle size (mm) | Loading weight (g/pot) | Crushing time (minutes) | Discharge particle size (mesh) | Power (kW) |
| GJ100-1 | 1 | <13 | 100×1 | <2 | 120-200 | 1.1 |
| GJ100-2 | 2 | <13 | 100×2 | <2 | 120-200 | 1.1 |
| GJ100-3 | 3 | <13 | 100×3 | <2 | 120-200 | 1.5 |
| GJ100-4 | 4 | <13 | 100×4 | <3 | 120-200 | 1.5 |
| GJ100-5 | 5 | <13 | 100×5 | <3 | 120-200 | 1.5 |
| GJ100-7 | 7 | <13 | 100×7 | <3 | 120-200 | 1.5 |
| GJ200-1 | 1 | <20 | 200×1 | <3 | 120-200 | 1.5 |
| GJ200-2 | 2 | <20 | 200×2 | <3 | 120-200 | 1.5 |
| GJ200-3 | 3 | <20 | 200×3 | <3 | 120-200 | 1.5 |
| GJ200-4 | 4 | <20 | 200×4 | <3 | 120-200 | 1.5 |
| GJ400-1 | 1 | <26 | 400×1 | <3 | 120-200 | 1.5 |
| GJ400-2 | 2 | <26 | 400×1 | <3 | 120-200 | 1.5 |
| GJ400-3 | 3 | <26 | 400×1 | <3 | 120-200 | 1.5 |
| GJ400-4 | 4 | <26 | 400×1 | <3 | 120-200 | 1.5 |
| GJ500-1 | 1 | <26 | 500×1 | <3 | 120-200 | 1.5 |
| GJ000-1 | 2 | <26 | 1000×1 | <3 | 120-200 | 1.5 |
| GJ100/200-Ⅰ | Separate system | <13/<12 | 100/200 | <2 | 120-200 | 1.5 |
| GJ300/400-Ⅱ | Separate system | <23/<26 | 300/400 | <2 | 120-200 | 1.5 |
Company profile
Y&X Beijing Technology Co., Ltd. was established in 2014 and is located in Beijing, the capital of China. Our company has become a professional enterprise integrating scientific research, design, new product development, production and manufacturing with strong technical force. As a family group, the mission from the beginning was to expand overseas markets and provide one-stop professional for overseas mining companies.
The company specializes in the research and supply of mineral processing reagents and equipments, including mineral processing equipment and laboratory mineral processing equipment; products are widely used in metallurgy, geology, petroleum, coal, chemicals, building materials, environmental protection, non-ferrous and non-metallic mines, Research departments in industries such as dressing plants, mineral processing laboratories in colleges and universities.
Laboratory equipment for mineral processing: mainly include crushing, grinding, screening, grading, magnetic separation, flotation, assay, sample preparation, leaching, analysis-electrolysis, shaking table, chute and other laboratory equipment and gravity separation equipment.
Our products sell well in Russia, Mongolia, Chile, Australia, Zimbabwe, Thailand, Laos, Indonesia,Tanzania, Nigeria and other countries and regions.
