Product Details:
|
| Name: | Disc Pulverizer, Disk Mill For Laboratory, Lab Milling Machine | Attributes: | Disc Pulverizer, Disk Mill |
|---|---|---|---|
| Keyword: | Disk Mill For Laboratory | Classficiation: | Lab Milling Machine |
| Applicable Industries: | Building Material | Core Components: | Bearing, Motor, Engine |
| Machine Type: | Grinder Mill | Application: | Coal, Power |
| High Light: | iso lab disc mill,coal laboratory disc mill,1.1kw laboratory disc mill |
||
Disc Pulverizer, Disk Mill for Laboratory, Lab Milling Machine
Introduction
Shaking table,as one of the gravity mining machines,applicable to nonferrous metals,ferrous metals and rare metals mineral,like gold,tungsten,tin,tantalum,iron,manganese,chrome,titanium,bismuth and lead,which the size ranges from 2-0.037mm,also recovery of Au,Cu,Ag from various of slags,PCB,waste wire and cable,battery scrap,to improve recovery ratio and protect environment.
Main uses and characteristics:
GJ type sealed series laboratory sample preparation pulverizer adopts the "anti-loosening device for pressing the material bowl", which is light and reliable. Fully sealed, no dust spillage, no need for exhaust and dust removal. High-frequency vibration grinding, high grinding efficiency, uniform particle size, no mixing, no need to sieve and divide. Users can choose different varieties according to the sample size; the product is small in size, compact in structure, no installation, low noise < 60 decibels, and can work in any place.
Parameter
| The main technical parameters | ||||||
| parameter item Specification model" |
Number of samples (pieces) | Loading particle size (mm) | Loading weight (g/pot) | Crushing time (minutes) | Discharge particle size (mesh) | Power (kW) |
| GJ100-1 | 1 | <13 | 100×1 | <2 | 120-200 | 1.1 |
| GJ100-2 | 2 | <13 | 100×2 | <2 | 120-200 | 1.1 |
| GJ100-3 | 3 | <13 | 100×3 | <2 | 120-200 | 1.5 |
| GJ100-4 | 4 | <13 | 100×4 | <3 | 120-200 | 1.5 |
| GJ100-5 | 5 | <13 | 100×5 | <3 | 120-200 | 1.5 |
| GJ100-7 | 7 | <13 | 100×7 | <3 | 120-200 | 1.5 |
| GJ200-1 | 1 | <20 | 200×1 | <3 | 120-200 | 1.5 |
| GJ200-2 | 2 | <20 | 200×2 | <3 | 120-200 | 1.5 |
| GJ200-3 | 3 | <20 | 200×3 | <3 | 120-200 | 1.5 |
| GJ200-4 | 4 | <20 | 200×4 | <3 | 120-200 | 1.5 |
| GJ400-1 | 1 | <26 | 400×1 | <3 | 120-200 | 1.5 |
| GJ400-2 | 2 | <26 | 400×1 | <3 | 120-200 | 1.5 |
| GJ400-3 | 3 | <26 | 400×1 | <3 | 120-200 | 1.5 |
| GJ400-4 | 4 | <26 | 400×1 | <3 | 120-200 | 1.5 |
| GJ500-1 | 1 | <26 | 500×1 | <3 | 120-200 | 1.5 |
| GJ000-1 | 2 | <26 | 1000×1 | <3 | 120-200 | 1.5 |
| GJ100/200-Ⅰ | Separate system | <13/<12 | 100/200 | <2 | 120-200 | 1.5 |
| GJ300/400-Ⅱ | Separate system | <23/<26 | 300/400 | <2 | 120-200 | 1.5 |
Company profile
Y&X Beijing Technology Co., Ltd. was established in 2014 and is located in Beijing, the capital of China. Our company has become a professional enterprise integrating scientific research, design, new product development, production and manufacturing with strong technical force. As a family group, the mission from the beginning was to expand overseas markets and provide one-stop professional for overseas mining companies.
The company specializes in the research and supply of mineral processing reagents and equipments, including mineral processing equipment and laboratory mineral processing equipment; products are widely used in metallurgy, geology, petroleum, coal, chemicals, building materials, environmental protection, non-ferrous and non-metallic mines, Research departments in industries such as dressing plants, mineral processing laboratories in colleges and universities.
Our products sell well in Russia, Mongolia, Chile, Australia, Zimbabwe, Thailand, Laos, Indonesia,Tanzania, Nigeria and other countries and regions.
The enterprise has passed the IS09001 quality management system certification, and the product quality conforms to the relevant technical standards promulgated by the state and the enterprise.
FAQ to save your precious time!
Q1: What's the standard length of your profiles and tube?
A: The standard length of profiles and tube are 5800mm to suit for small container, and we also can cut to specific length, however a surcharge of machining and material scrap cost will be charged accordingly based on each individual invoice.
Q2: What's your MOQ?
A: we have no MOQ for our new customers, however a surcharge of USD80 will apply for all orders less that USD 1000 for custom handing cost purpose.
Q3: what is your payment terms?
A: The payment terms we accept is T/T or irrevocable L/C at sight, T/T preferred.
Q4: What's the lead time for small order and mass production?
A: 1-3 working days for small order, and 3-10 working days for mass production of material, and the final lead time will be subject to each individual invoice.
Q5: What certification do you have?
A: We have ISO 9001:2008 certificate.
