600mm Multi-layer Rotary Vibrating Screen Machine for Mine Industry

MOQ: 1
Price: Negotiate
Standard Packaging: Standard export packing is provided, and customized packing is available upon request.
Delivery Period: 1-3 working days
Payment Method: T/T,L/C
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Y&X
Certification
Iso 9001
Model Number
rotary vibrating screen
Name:
Rotary Vibrating Screen
Type:
YZS-φ600 Type
Model:
Rotary
Application:
Food Industry, Mine
Material:
Sugar, Salt,
Feature:
Multi-layer Vibrating Screen
Motor:
The Latest Vertical Vibration Motor
YZS-1000:
1.1kw
Highlight:

yzs 600mm type screen vibration machine

,

1.1kw screen vibration machine

,

rotary vibrating sand screening machine

Product Description
600mm Multi-layer Rotary Vibrating Screen Machine for Food Industry
Product Overview

The YZS-600 multi-layer rotary vibrating screen machine is a 600 mm-class unit that combines high screening efficiency with a small footprint. Driven by a vertical vibration motor, it produces a three-dimensional motion that spreads feed material evenly over the sieve surface, making it a practical choice for food, chemical and sand-processing workshops that need clean fractions without long screening lines.

YZS Vibrating Screen Machine Diagram600mm Multi-layer Rotary Vibrating Screen Machine for Mine Industry
Construction and Materials

The multi-layer vibrating screen machine of our normal specification uses stainless steel SUS27 (#304) for the parts where the body and raw materials come into contact, and steel for the machine frame. This gives good resistance to wear and corrosion while keeping the machine affordable for routine production screening.

Key Features
  • 600 mm-class rotary screen for medium-capacity production lines
  • Multi-layer decks separate feed into several size fractions at the same time
  • Vertical vibration motor delivers three-dimensional screening motion
  • Stainless steel contact surfaces protect product quality in food service
Typical Materials

Typical duties include sugar, salt and milk powder screening in food plants, quartz sand and alumina classification in abrasive and ceramic production, resin and pigment screening in the chemical industry, and metal powder or titanium oxide classification in metallurgical applications.

Technical Specifications - YZS Type Rotary Vibrating Screen (1)
Parameter Item Power (kw) Screen Diameter (mm) Dimensions (mm) Number of Network Layers
YZS-400 -1s 0.25 350 580*580*560 1
YZS-400 -2s 0.25 350 580*580*670 2
YZS-400 -3s 0.25 350 580*580*780 3
YZS-600 -1s 0.55 550 800*800*750 1
YZS-600 -2s 0.55 550 800*800*890 2
YZS-600 -3s 0.55 550 800*800*1030 3
YZS-800 -1s 0.75 750 900*900*750 1
YZS-800 -2s 0.75 750 900*900*890 2
YZS-800 -3s 0.75 750 900*900*1030 3
YZS-1000 -1s 1.1 920 1160*1160*810 1
YZS-1000 -2s 1.1 920 1160*1160*950 2
YZS-1000 -3s 1.1 920 1160*1160*1090 3
YZS-1200 -1s 1.5 1120 1360*1360*885 1
YZS-1200 -2s 1.5 1120 1360*1360*1050 2
YZS-1200 -3s 1.5 1120 1360*1360*1275 3
YZS-1500 -1s 2.2 1420 1850*1850*990 1
YZS-1500 -2s 2.2 1420 1850*1850*1185 2
YZS-1500 -3s 2.2 1420 1850*1850*1380 3
YZS-1800 -1s 2.2 1720 2200*2200*1050 1
YZS-1800 -2s 2.2 1720 2200*2200*1250 2
YZS-1800 -3s 2.2 1720 2200*2200*1450 3
Technical Specifications - YZS Type Rotary Vibrating Screen (2)
Center of Gravity Angle Featured Effects The Main Purpose
5° The raw material system flows straight from the center to the circumferential direction Rough grading classify the materials that are easy to sieve in large quantities, and sieve coarse particles
15° Start whirlpool movement General screening
85° Longest vortex distance Precise classification, used to differentiate raw materials with high cohesion and high moisture content
100° Centralized raw materials Special Purpose
Company Profile

Y&X Beijing Technology Co., Ltd. was established in 2014 and is located in Beijing, the capital of China. Our company has evolved into a professional enterprise integrating scientific research, design, new product development, production and manufacturing with strong technical force. Our products sell well in Russia, Mongolia, Chile, Australia, Zimbabwe, Thailand, Laos, Indonesia, Tanzania, Nigeria and other countries and regions.

Y&X Beijing Technology Co., Ltd. Facility
