XDF 250MM 200MM High Voltage Electrostatic Separator High Intensity

I'm Online Chat Now

XDF 250MM 200MM High Voltage Electrostatic Separator High Intensity

XDF 250MM 200MM High Voltage Electrostatic Separator High Intensity
XDF 250MM 200MM High Voltage Electrostatic Separator High Intensity

Large Image :  XDF 250MM 200MM High Voltage Electrostatic Separator High Intensity

Product Details:
Place of Origin: China
Brand Name: Y&X
Certification: ISO9001
Model Number: High Voltage Electrostatic Separator
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: Cartons
Delivery Time: 1-3 working day
Payment Terms: T/T, L/C

XDF 250MM 200MM High Voltage Electrostatic Separator High Intensity

Name: High Voltage Electrostatic Separator Model: Electrostatic
Classification: Separator Advantage: High Voltage
Type: XDF- Φ250x200 Drum(Diameter×Length): Φ250×200mm
Drum Speed: 50~300R/min Corona Electrode(Polarfilament Diameter): 1~5Piece
High Light:

250MM high voltage electrostatic separator


200MM high voltage electrostatic separator


300R/min high intensity magnetic separator

XDF- Φ250x200 High Voltage Electrostatic Separator


XDF-Φ250x200 high-voltage electrical separator is mainly used for the separation of conductor minerals and non-conductor minerals. It can also be used for the classification of the same material and the sorting work in part of the seed selection work instead of the screening work.


Technical Parameters:

 Item Value  Unit
 Drum(Diameter×Length) Φ250×200 mm
 Drum Speed 50~300 R/min


Corona electrode(Polarfilament Diameter)

0.2 mm
1~5 bar


Static level(Diameter×Length)

1 bar
Φ30 mm


Electrode Regulator

 Radial movement 50 mm
Circumferential Angle 60   ℃


Hairbrush(Out diameter×Diameter)

Φ105×60 mm
 Hairbrush Veer 2 times of drum speed




Temperature 50~60
 Power 900 w




Temperature 100~300
 Power 900 w
 Bin Stopper Opening Scale 0~20 mm
Feeding chute Obliquity 0~30 °
 Feeding chute Vibrator  Adjustable (0~220v)
 Handling material Size 0.04~1 mm
 Throughput 15~30 Kg/h


Power of Highvoltagepowersupply

800 w
 Max. Voltage 60 Kv
 Outline Size 920×1120×1850 mm
Weight 400 kg


Company profile
Y&X Beijing Technology Co., Ltd. was established in 2014 and is located in Beijing, the capital of China. Our company has become a professional enterprise integrating scientific research, design, new product development, production and manufacturing with strong technical force. As a family group, the mission from the beginning was to expand overseas markets and provide one-stop professional for overseas mining companies.
The company specializes in the research and supply of mineral processing reagents and equipments, including mineral processing equipment and laboratory mineral processing equipment; products are widely used in metallurgy, geology, petroleum, coal, chemicals, building materials, environmental protection, non-ferrous and non-metallic mines, Research departments in industries such as dressing plants, mineral processing laboratories in colleges and universities.
Laboratory equipment for mineral processing: mainly include crushing, grinding, screening, grading, magnetic separation, flotation, assay, sample preparation, leaching, analysis-electrolysis, shaking table, chute and other laboratory equipment and gravity separation equipment.
Our products sell well in Russia, Mongolia, Chile, Australia, Zimbabwe, Thailand, Laos, Indonesia,Tanzania, Nigeria and other countries and regions.
The enterprise has passed the IS09001 quality management system certification, and the product quality conforms to the relevant technical standards promulgated by the state and the enterprise.
XDF 250MM 200MM High Voltage Electrostatic Separator High Intensity 0

1: What's the standard length of your profiles and tube?

A: The standard length of profiles and tube are 5800mm to suit for small container, and we also can cut to specific length, however a surcharge of machining and material scrap cost will be charged accordingly based on each individual invoice.


Q2: What's your MOQ?

A: we have no MOQ for our new customers, however a surcharge of USD80 will apply for all orders less that USD 1000 for custom handing cost purpose.


Q3: what is your payment terms?

A: The payment terms we accept is T/T or irrevocable L/C at sight, T/T preferred.


Q4: What's the lead time for small order and mass production?

A: 1-3 working days for small order, and 3-10 working days for mass production of material, and the final lead time will be subject to each individual invoice.


Q5: What certification do you have?

A: We have ISO 9001:2008 certificate.
