High Throughput Fire Assay Crucible Mixer 84 Crucible Batch Sample Homogenizer 380V
  • name
  • name

High Throughput Fire Assay Crucible Mixer 84 Crucible Batch Sample Homogenizer 380V

MOQ: 1 Set
Price: Negotiate
Standard Packaging: Standard export packing is provided, and customized packing is available upon request.
Delivery Period: 15-30 working days
Payment Method: L/C,T/T
Supply Capacity: 50 Sets per Month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Y&X
Certification
ISO 9001
Model Number
Fire Assay Crucible Mixer
Product Type:
Fire Assay Crucible Mixing Machine
Application:
Fire Assay Crucible Sample Mixing
Crucible Batch Capacity:
84 Pcs
Mixing Mechanism:
Worm Gear Reduction Drive
Max Rotation Speed:
60 Rpm
Max Setting Time:
60 Minutes
Door Safety:
Interlock Protection Switch
Air Supply:
Pneumatic Switch, 0.4-0.5 MPa
Voltage:
380V, 50Hz, 3-Phase
Overall Dimension:
2600 X 1270 X 1250 Mm
Highlight:

Fire Assay Crucible Mixer 84 Batch

,

380V Fire Assay Sample Homogenizer

,

High Throughput Fire Assay Mixer

Product Description
DPT84 Fire Assay Crucible Mixer for High Throughput Sample Preparation

The DPT84 Fire Assay Crucible Mixer is engineered for high throughput fire assay laboratories that process large crucible batches every shift. With an 84-crucible batch capacity and a forklift-compatible crucible loading arrangement, it shortens handling time and accelerates the sample preparation cycle. The worm gear drive ensures fast, uniform mixing across the entire batch.

Key Features
84-Crucible High Throughput Batch

A single cycle mixes up to 84 crucibles, and the batch quantity can be customized to match the required sample volume.

Forklift-Compatible Loading

The machine is arranged for use with a crucible loading forklift, improving efficiency and simplifying operation.

Worm Gear Rapid Homogenizing

The worm gear reduction drive delivers fast mixing speed, short mixing time, and a thoroughly uniform blend.

Interlock Safety Door

An interlock protection switch prevents door opening during operation and stops the machine immediately in an unexpected door-opening event.

Technical Specifications
Model DPT84
Crucible Batch Capacity 84 pcs
Compatible Crucible Weight 40g / 50g / 55g
Mixing Mechanism Worm Gear Reduction Drive
Max Rotation Speed 60 rpm
Max Setting Time 60 minutes
Control Mode Touchscreen HMI
Door Safety Interlock Protection Switch
Air Supply Pneumatic Switch, 0.4–0.5 MPa
Voltage 380V, 50Hz, 3-Phase
Power 3.0 kW
Overall Dimension 2600 × 1270 × 1250 mm
Note: Crucible batch capacity can be customized to the required sample volume. Please confirm crucible weights and batch quantity before ordering.
How It Works
  • 1. Fire assay crucibles are loaded into the mixing chamber and the door is closed.
  • 2. The touchscreen controller starts the programme, and the worm gear reduction drive rotates the chamber to blend the crucible contents.
  • 3. The gear drive produces fast, uniform mixing, so large batches of crucibles can be homogenised within a short cycle time.
Applications
  • Gold and silver fire assay laboratories
  • Precious metal analysis laboratories
  • Mining and mineral testing laboratories
  • Metallurgical and refining laboratories
Frequently Asked Questions
Q1: How many crucibles can be mixed in one batch?

84 crucibles can be mixed in a single batch, and the quantity can be customized.

Q2: Can the mixing quantity be customized?

Yes. The standard batch capacity can be adjusted to suit the required sample volume.

Q3: Is the machine safe to operate?

The door is fitted with an interlock protection switch. The door cannot be opened while the machine runs, and the machine cannot start with the door open.

About Y&X

Y&X Beijing Technology Co., Ltd. supplies laboratory equipment for fire assay, mineral processing, sample preparation, and mineral analysis. We help customers select crucible mixers according to batch size, crucible specification, and laboratory conditions.
