Laboratory Spiral Classifier Machine for Industrial Laboratories

I'm Online Chat Now

Laboratory Spiral Classifier Machine for Industrial Laboratories

Laboratory Spiral Classifier Machine for Industrial Laboratories
Laboratory Spiral Classifier Machine for Industrial Laboratories

Large Image :  Laboratory Spiral Classifier Machine for Industrial Laboratories

Product Details:
Place of Origin: China
Brand Name: Y&X
Certification: ISO9001
Model Number: spiral classifier
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: Cartons
Delivery Time: 1-3 working day
Payment Terms: T/T, L/C

Laboratory Spiral Classifier Machine for Industrial Laboratories

Name: Laboratory Spiral Classifier Machine For Industrial Laboratories Keyword: Laboratory Spiral Classifier Machine
Application: Industrial Laboratories Energy Saving: Energy Saving
Spiral Dia (mm): 2400 Trough Length (mm): 9500
Spiral Speed (R/Min): 3.67
High Light:

anti corrosion spiral classifier machine


wear resistant spiral classifier machine

Laboratory Spiral Classifier Machine for Industrial Laboratories


Uses and characteristics.

This machine is suitable for dewatering, desliming and dry-wet grading of non-metallic ores in geological, metallurgical and other units and concentrator laboratories. With the help of the principle of different size of solid particles, different specific gravity and different settling speed in the liquid, the fine ore particles float in the water and overflow, and the coarse ore particles sink to the bottom of the tank, which is pushed up by the screw to be removed, and the powder in the mill is filtered separately, and then screw the coarse material into the feed port. The lifting device is divided into two types: electric and manual


1. Reasonable structure and small occupation area.
2. High recovery, high efficiency, and precise separation
3. Non-required power
4. anti corrosion, rust and wear resistant
5. Simple installation and Minimum maintenance requirements.
6. Low operating cost and long working life.
7. Strong adaptability to fluctuation of feeding amount, density, size and grade



Main technical parameters of FG type single spiral classifier
Project Unit FG-100×1200 FG-150×1200 FG-200×1650
Spiral size mm Φ100×1200 Φ150×1200 Φ200×1650
Pitch mm 80 100 120
Groove inclination angle (°) 10°~30°
Spiral speed r/min 18,23,30
Processing capacity kg/h 30 60 80
Motor Power Kw 0.4,0.25 0.6,0.4 1.0,0.6
Voltage V 220,380
Dimensions mm 1500×320×700 1574×320×740 1600×350×750
Weight kg 66 76 82


Company profile

Y&X Beijing Technology Co., Ltd. was established in 2014 and is located in Beijing, the capital of China. Our company has become a professional enterprise integrating scientific research, design, new product development, production and manufacturing with strong technical force. As a family group, the mission from the beginning was to expand overseas markets and provide one-stop professional for overseas mining companies.

The company specializes in the research and supply of mineral processing reagents and equipments, including mineral processing equipment and laboratory mineral processing equipment; products are widely used in metallurgy, geology, petroleum, coal, chemicals, building materials, environmental protection, non-ferrous and non-metallic mines, Research departments in industries such as dressing plants, mineral processing laboratories in colleges and universities.

Laboratory equipment for mineral processing: mainly include crushing, grinding, screening, grading, magnetic separation, flotation, assay, sample preparation, leaching, analysis-electrolysis, shaking table, chute and other laboratory equipment and gravity separation equipment.
